Electro-Voice EKX-18SP 18 inch Active PA Subwoofer

Electro-Voice EKX-18SP 18 inch Active PA Subwoofer

Outstanding bass. Every single time. The Electro-Voice EKX-18SP Powered 18'' Subwoofer offers articulate low end with 1600W peak power output. Give your talent impact with a high-sensitivity transducer. You'll get deep, responsive lows with enough punch to knock your audience off their feet.

Perform with confidence. Whether on stage or in installation systems, the EKX-18SP promises best-in-class performance with an intuitive QuickSmart DSP. Dial your sound with the user-friendly LCD display. And thanks to class-D amplification, you get huge power from a compact enclosure.

Reliability guaranteed. The Electro-Voice EKX-18SP brings great sound to the most challenging environments. With intelligent thermal managing, scratch resistant coating, and robust wooden enclosure, you'll never have to worry about damages getting in the way of the show.

The new face of bass

Consistent performance guaranteed. The EKX-18SP is perfect for use as a single sub, or when multiple subs are deployed. Thanks to Cardioid Control Technology, this flexible speaker can be steered towards the audience with up to 35dB reduction on stage. And with large slot ports on board, you’ll get minimised distortion, and excellent bass extension. This is live sound with a difference.

Ultimate performance

QuickSmartDSP offers best-in-class processing for easy setup and phenomenal sound. Take advantage of a wide range of user-programmable presets for instantly optimised audio. It’s as easy as plug in and play.

Professional hardware

The EKX-18SP is fitted with professional-grade hardware for exceptional flexibility and ease-of-use. The M20 threaded pole mount plate allows you to stack your speaker with confidence. And when it comes to transportation and manoeuvrability, the lightweight cabinet is easy to carry thanks to EV’s ergonomic handles.

Features

• Perfect for live and installation applications

• Huge power with 1600W peak output

• Exceptional bass response from an 18” woofer

• Ultra-efficient class D amplifier

• Great sound at high volumes with up to 134dB peak SPL

• Best-in-class processing from a QuickSmart DSP

• Easy to use user interface with LCD screen and single rotary knob

• Steer towards the audience with up to 35dB reduction when multiple subs are deployed

• Easy system expansion from two integrated XLR outputs

• Superior performance in demanding environmental conditions thanks to an intuitive thermal management system

• Lightweight and compact enclosure for ultimate practicality

• Minimised distortion thanks to large slot ports

• Scratch and scuff resistant EVcoat finish

• Easy to setup thanks to M20 threaded pole mount plate and comfortable handles

Specifications

• Frequency Response (-3 dB): 50 Hz - 100 Hz Half Space Measurement

• Frequency Range (-10 dB): 35 Hz - 300 Hz Half Space Measurement

• Axial Sensitivity (SPL, 1 W @ 1 m): 95 dB

• Maximum SPL: 134 dB Maximum SPL is measured at 1 m using broadband pink noise at rated peak power rating

• Recommended High-Pass Frequency: 30 Hz

• Coverage (H x V): 90 x 60

• Power Handling (Continuous / Peak): 400 W/1600 W

• LF Transducer: EVS-18C 457 mm (18 in)

• Nominal Impedance: 8 Ω

• Minimum Impedance: 7.0 Ω

• Connector Type: Dual NL4

• Enclosure Material: 15 mm, plywood with EVCoat

• Grill: 18 AWG steel with powdercoat

• Dimensions (H x W x D): 520 mm (20.47") x 606 mm (23.86") x 612 mm (24.09")

• Net Weight: 31.8 kg (70.11 lbs)

• Shipping Weight: 40.1 kg (88.41 lbs)
