Electro-Voice PXM-12MP 12 inch Powered Coaxial Floor Monitor

Electro-Voice PXM-12MP 12 inch Powered Coaxial Floor Monitor

Monitor with confidence.The Electro-Voice PXM-12MP Powered Coaxial Floor Monitor lets you hear every single detail of your sound with unmatched clarity and precision. Boasting a powerful Dynacord-designed 700W Class-D power amp, a 12''/1.75'' coaxial driver with a symmetrical coverage pattern, and best-in-class QuickSmart digital signal processing, your monitoring will never be the same again.

Take advantage of built-in and user programmable presets for quick setups, configure a full system with ease thanks to sub/top matching LPFs. Thanks to flexible connectivity you'll be able to hook up everything instantly with total ease. All the parameters you need can be adjusted directly from the easy-to-read LCD on the PXM-12MP itself, whilst a rugged, endurance-tested design ensures reliable performance night after night.

Features

• Multi-functional monitoring system for use as a high-performance floor monitor or main PA

• Acoustically-optimised 55° floor monitor angle

• QuickSmartDSP provides best-in-class processing

• Easy to setup with four built-in presets and five user-programmable presets

• Sub/top system matching

• Three-band equalisation for shaping your sound

• Visual monitoring of the limiter status

• Input level control and metering

• Master volume control to optimise your gain structure

• All parameter adjustments and processed accessed via an easy-to-read LCD

• 700W Class-D power amp designed by Dynacord

• Delivers peak SPLs of up to 129dB

• Utilises high-quality transducers designed and created by Electro-Voice

• System reliability verified with over 500 hours of abuse and endurance testing

Specifications

• Frequency Response:

• -3dB: 64Hz - 20kHz

• -10dB: 53Hz - 20kHz

• Maximum SPL: 129dB

• Coverage: 90° x 90°

• Amplifier Rating: 700W (500W+200W)

• Crossover Frequency: 1.6kHz

• Transducer: CXCA2128-1NA 12''/1'' 2-way coaxial

• Connectors: 2 x XLR/TRS combo inputs, 1 x stereo RCA input, 1 x XLR THRU input

• Enclosure: 15mm plywood

• Grille: Steel with black powder coat

• Colour: Black

• Power: 100-240VAC, 50-60Hz, 0.8-0.5A

• Dimensions: 334mm x 409mm x 484mm

• Weight: 13.5kg
